STANLEY® FATMAX® Cross Beam and 2 Spot Laser Level Red
FMHT1-77414
STANLEY® FATMAX® Cross Beam and 2 Spot Laser Level Red
- CROSS LINE LASER BEAM PROJECTION: With 1 x horizontal and 1 x vertical line to create a cross line plus 2 independent spot points (plumb up and down)
- RED BEAM LASER: With a visible working range of up to 20M; up to 50M with a detector
- PRECISION AND ACCURACY: +/- 3mm at 10m
Product Overview
FATMAX® cross - 2 spot - red
Additional Features
- IP RATED TO IP54: Protects against dust and water spray
- PENDULUM LOCK: For safe transportation
- PULSED BEAM MODE: Allows for use with a detector over an extended working range, up to 50m
- RUNS ON:4xAA NiMH (supplied)
- INCLUDES: Multi Bracket, Glasses, Battery Charger
- 150° FAN ANGLE: Providing ample coverage with little set-up time
- Multi-Bracket, Glasses
- TRIPOD THREAD: 1/4” & 5/8" thread allows the unit to be mounted to a tripod
- SPOT WORKING RANGE of 30m
- DOWN BEAM: With raised clearance provides line visibility and alignment for all track layout
Includes
- (1) Kit box
Specifications
|
Laser Accuracy
|
+/-3mm@10m
|
|
Materials Housing
|
Plastic
|
|
Working Distance with Detector [Metric]
|
50 m
|
|
Product Width [Metric]
|
35 cm
|
|
Battery Run Time Hrs.
|
30+
|
|
CE Mark
|
Yes
|
|
Number of Beams
|
2
|
|
Product Height [Metric]
|
18 cm
|
|
Product Weight [Metric]
|
3.347 Kg
|
|
Visible Working Distance [Metric]
|
20 m
|
|
Line Diagram
|
Cross Line
|
|
Battery Source
|
Alkaline Battery (AA)
|
|
Display Type
|
N/A
|
|
Laser Beam Color
|
Red Beam
|
|
Number of Pieces
|
5
|
|
Leveling Type
|
Self-leveling
|
|
Product Weight Gross [Metric]
|
3.347 Kg
|
|
Packaging
|
Plastic Case
|
|
Product Length [Metric]
|
44 cm
|
|
Is it a Set
|
No
|
|
Number of Batteries Included
|
4
|
Support
Warranty
- 1 Year Warranty
We're confident of the quality of our products and we'll repair, without charge, any defects due to faulty materials or workmanship within the specified warranty.
Service
We take extensive measures to ensure all our products are made to the very highest standards but on the rare occasion that you need our help & support, we've got you covered. Just get in touch.
